2000 Tiara Yachts 35' _{(10.67 m)} 3500 Open

Manufacturer Provided Description

The Tiara 3500 Open features a stepped cockpit with an over 60-square-foot upper and 67-square-foot lower cockpit. Available in either gas or diesel power, the 3500 has engine access thru upper cockpit drop-down hatch, or lower cockpit electric engine hatch lift. Seating includes double-wide back-to-back helm seat, with top-loading cooler - storage box, and port back-to-back companion seats, with storage - wet bar - entertaining center. The 3500 features Tiara's tilt-away helm and chart flat console with deep-blue non-glare. There are three full-size opening foredeck hatches, and six opening hullside portlights with screens. The integrated swim platform has a folding swim ladder. TIARA YACHTS FEATURES: Over forty years of boat building results in yachts of uncommon style and performance. Tiara's deep-V hull gives a quick planing, fuel efficient, stable, dry ride, and the advanced keel design maximizes tracking and maneuverability. Stringer systems are constructed of strong, lightweight materials, and hullsides and decks are balsa-cored, resulting in excellent structural strength-to-weight ratio. Hull - deck joints are sealed with a combination of polyurethane membrane and fasteners every six to eight-inches, eliminating any leaks. Cockpit and deck are of one-piece construction, greatly increasing overall strength, and further ensuring a watertight fit. Master hull and deck molds are hand-sanded, creating a perfect mold. Hulls and decks are laid-up by hand, resulting in a smooth, distortion-free and long lasting finish. Engine rooms, hatches and overheads are gelcoated, as are all bilge and storage compartments - resulting in finished and stain-resistant surfaces throughout. Large scuppers and gutters, and channeled cockpit hatches ensure quick drainage of water and debris. Scupper and gutter baffles prevent water entry when backing down. Cockpit seating has a base of durable, non-rotting, waterproof polyethylene seat framing. Cushions feature quick-drying, drain-fast foam. All Tiara Open and Express helm consoles are one-piece molded fiberglass units that tilt aft for clear access-for easy service. Instrumentation is laid out in function - usage clusters for improved operator visibility, and each panel layout allows ample room for a variety of custom electronics. Custom Tiara diamond nonskid provides sure, safe footing on all deck surfaces. The strongest in the industry, Tiara windshields are more than aesthetically pleasing - they are built for maximum visibility and protection. All deck fittings and hardware are recessed for safety, and through-bolted with backup plates. Integrated molded-in bow pulpits include anchor roller assemblies, and anchor lockers are self-draining. Below deck, interiors are executed with fine fabrics, plush carpets, supple leathers and exquisite woodwork. All primary harnesses are built in-house, and tie wrapped, with cushioned clamps, anti-chafe collars, and meet ABYC standards. Model to model, Tiara engine selections are designed to give optimum performance and efficiency. As are underwater gear propellers, custom designed for each particular model. Tiara Yachts offers a five-year transferable warranty on hull - deck and cockpit - and all applicable warranties on outside manufacturer sources.

General Information

GENERAL INFORMATION

NAME OF VESSEL: . . . . . . . . . . . . . . . . . . . . . . . . . . Robin's Nest

YEAR/MAKE/MODEL OF VESSEL: . . . . . . . . . . . . . . . 2000 Tiara 3500 Open

HULL IDENTIFICATION NUMBER (HIN): . . . . . . . . . . SSUR4122H900

ENGINE #'S: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Twin turbo charged diesel inboards by Cummins

rated 370hp at 3000rpm each.

Model : 6BTA5.9-M3

Port Serial : 45880100

Starboard Serial : 4588011

USCG DOCUMENTATION NUMBER: . . . . . . . . . . . . 1089586

HULL MATERIAL: . . . . . . . . . . . . . . . . . . . . . . . . . . . FRP (Fiber Reinforced Plastic)

HULL TYPE: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Planing, Modified-V

LENGTH OVER ALL (L.O.A).: . . . . . . . . . . . . . . . . . . . 40' 8"

BEAM: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13' 3"

DRAFT: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3' 3"

DEPTH: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.2'

DISPLACEMENT: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14,000 #

GROSS TONS: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

NET TONS: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

FUEL CAPACITY: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 352 gallons, labeled

AC POWER: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Two (2) 125 volt, 30 amp inlets with auxiliary

generator

DC POWER: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 volt

FRESH WATER CAPACITY: . . . . . . . . . . . . . . . . . . . . 70 gallons

HOLDING TANK: . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes, USCG marine sanitation device type III,

DRIVE TYPE: Twin straight drive inboards by ZF Marine

Model : IRM 220A-1

Port Serial : 19225H

Starboard Serial : 19221H

GEAR RATIO: Transmission tag: 2.04 to 1 ratio.

DECK FITTINGS

BOW PULPIT (BOW RAIL): Welded stainless steel bow rail

TOE RAILS: Molded FRP toe rails, part of deck layup.

HATCHES Three deck hatches forward, portlights port and starboard. forward hatch

doubles as a cabin emergency exit. Two deck hatches above the helm, hardtop

SCUPPERS Decks drain overboard. Cockpit is equipped with gutter drains port and starboard aft and

two plastic tubes draining overboard topsides

MOORING CLEATS: Seven stainless steel mooring cleats

WINDLASS/GROUND TACKLE SYSTEM: Lewmar 12 volt windlass with deck and helm controls, operable at

both. Fortress fluke style aluminum anchor with galvanized chain rode and marine grade nylon rode

GRAB RAIL: Powder coated hand rails along sides of super structure and others at various locations on

vessel.

ANCHOR PLATFORM: FRP platform with removable anchor bow roller assembly.

SUPERSTRUCTURE

Cabin house with curved windshield, centerline vent, operable, and wipers, operable. Molded FRP arch

above. Three sided isen glass for helm area

BRIDGE DECK

Molded helm console starboard forward, adjacent to sliding pocket door, acrylic, for cabin entrance, also with separate sliding insect screen door. Power vent

windshield centerline with three wipers and washers

SEATS: Manual adjusting helm seat to starboard, operable, bench seating to port, basin with pressure

water to starboard aft.

Isotherm icemaker in the cockpit

Cockpit courtesy type lighting

Spreader lighting

Three blue/white underwater lights installed on the transom

CANVAS AND COVERS

Bimini top with stainless steel tubular supports and isen

glass forward also equipped with aluminum supports with lashed on white canvas aft of the arch

FISHING EQUIPMENT

ROD HOLDERS: Gunwale mounted

FISH BOX(S): Molded FRP lift out box below the cockpit sole centerline aft, with drainage direct into the

bilge

OUTRIGGERS: Aluminum single spreader outriggers both port and starboard

FAUCETS/FRESHWATER SYSTEM

Freshwater system is supplied from a polyethylene

tank, located centerline engine compartment. Pressure is supplied by two 12 volt pumps with an

inline screen/strainer and accumulator tank. The vessel is also equipped with a dockside water

pressure regulator inlet located starboard aft.

6 Gallon water heater by Atwood with a built in pressure relief valve.

HEAD/BLACKWATER SYSTEM

Electric flush head by Jabsco

Raw water supply is the vessel's fresh water system.

Waste is directed to a poly waste tank located port engine compartment and on to a deck pump out plate located side deck

Waste can also be discharged via a Y-valve and 12VDC diaphragm pumpthru a bronze, bonded, operable seacock

USCG Marine Sanitation Device type III, holding tank.

SHOWERS: Marine head compartment is equipped with a molded shower, with single lever mixer valve

and hose

Drainage is thru the sole to a plastic collection sump tank, equipped with a 12VDC Rule pump and float switch.

LIGHT FIXTURES

Cabin/courtesy lights throughout the vessel

CABIN SOLE: Teak and holly sole

AIR CONDITIONING UNIT 12,000 BTU air conditioning unit for the cabin area by Dometic.

Thermostat was of the digital touchscreen type. Reverse cycle for heating

TELEVISIONS: One Dynex 20" TV

STEREO: Sony DSX-M55BT receiver in the cabin with speakers in the cabin and cockpit,

GALLEY

NovaKool AC/DC refrigerator and freezer, a two burner. electric cooktop by Force10 with operable safety switch and a Kenmore elite stainless toaster oven.

ELECTRICAL SYSTEM (D.C. SYSTEM)

AGM battery powered 12 volt system.

Total of five (5) batteries,

CHARGING SYSTEM (BATTERY CHARGER): Charles Industries 12VDC 40 amp charger

CHARGING SYSTEM (ALTERNATOR): Belt driven alternators, 12VDC output, one each engine

MAIN BATTERY SWITCHES: Rotary style battery switches at the DC panel

SHORE POWER INLET: Two Marinco 30 amp, 125 volt inlet

SHORE POWER: Shore power cords

Various A.C. outlets available throughout yacht GFCI (ground fault circuit interrupter) protected outlets in galley, cockpit and marine head.

GALVANIC ISOLATOR: Two Quicksilver 30 amp galvanic insulators

GENERATOR

MANUFACTURER: Diesel powered generator by Westerbeke

Model : 5.0 BCDB

Serial : 42480-D908

Hours : 3000

KILOWATT RATING: 5 kW

VOLTAGE RATING: 120VAC 60hz

ELECTRONICS AND NAVIGATION EQUIPMENT

VHF: Icom IC-M506 and CommandMic vhf

RADAR/GPS/SOUNDER: Garmin 8212 and 5208 displays at the helm with Radar/GPS/Plotter/Sonar. Open

array Garmin GMR404 HD radar antenna mounted to the hardtop with a 72nm range.

AUTOHELM: Simrad AP11

COMPASSES: 5" Ritchie Powerdamp Plus

TRIM TABS: Bennett trim tab electric hydraulic system.

SAFETY EQUIPMENT

NUMBER AND TYPE OF PFD'S: Eight USCG type II pfd's

NUMBER OF THROWABLE PFD'S: Two USCG type IV

VISUAL DISTRESS SIGNALS: Day/night visual distress signals are 12ga flares with a launcher in a

waterproof container.

SOUND DEVICES: Horn

CARBON MONOXIDE DETECTORS: One each, Xintex CMD2M CO detector in the cabin

REBOARDING MEANS: Folding aluminum swim ladder at platform

BILGE PUMPS

LIST: Three 12 volt submersibles with remote float switches for the engine compartment pump and aft

bilge pump.

BELOW WATERLINE MACHINERY

PROPELLER(S): Two each, four bladed bronze wheels 23 x 28 Propspeed type coating.

PROPELLER SHAFT(S): Stainless steel 1 3/4".

STRUTS: Single I-beam strut per shaft, bronze.

RUDDER(S) MATERIAL: Bronze

TRIM TABS: Stainless trim tabs by Bennett

THRU-HULLS: All thru hull fittings are bronze in material.
