2003 Menorquin 41' _{(12.50 m)} 120

NEWLY REPLACED OR UPGRADED EQUIPMENT

• NEW 2024 - Fly Bridge Removed
• NEW 2024 - Headliner in Wheelhouse
• NEW 2024 - Canvas over aft Deck
• NEW 2024 - Two Stainless Steel Refrigerators
• NEW 2024 - Starboard Water Pump
• NEW 2024 - Fresh Water Pump
• NEW 2024 - Raw Water Seacock
• NEW 2024 - Radar / GPS Mast
• NEW 2024 - Hatch Seals
• NEW 2023 - Salon Door Exterior Canvas
• Rebuilt 2023 - Electrical Side of Generator
• NEW 2023 - Bottom Paint (2) Coats
• NEW 2023 - A/C Conductor
• NEW 2023 - Propspeed (coated props and shafts)
• NEW 2022 - Port EDC Power Unit
• NEW 2022 - Port & Starboard Turbo-Chargers
• NEW 2022 - Port & Starboard Risers
• NEW 2022 - All Exterior Teak Varnished
• NEW 2021 - Holding Tank
• NEW 2020 - Generator Battery
• NEW 2019 - HULL Painted Dark Blue (Awlgrip)
• NEW 2019 - Bow Thruster Battery 4 D
• NEW 2018 - House Batteries - 8 D's
• NEW 2018 - Engine Start Batteries - (2) 8 D's

YEARLY MAINTANCE

• Oil Changes
• Routine Engine Maintenance
• Replace Belts, Filters and Impellers (Both Engines and Generator)
• New Zincs
• Teak work Maintenance

GENERAL CONSTRUCTION

The Menorquin 120 has been constructed with the following:

• Solid fiberglass hull
• Solid fiberglass deck
• Deck, cabin top and passageway in non-skid material
• Integrated fiberglass swim platform, acting as stabilizing fins
• Bulkheads and furniture in teak
• Interior finishings in teak
• Anodized aluminum safety glass windows and portholes
• All interior and exterior wood is varnished

INTERIOR ACCOMMODATIONS

Main Salon:

• L-shaped sofa with dinette
• Storage under sofa
• Matching upholstery and curtains
• Halogen ceiling lights
• Wooden floor throughout interior, sapele wood (in mahagony family) and white pine planking
• Automatic and manual bilge

Seperate Master Stateroom:

• Large double bed
• Curtains
• Closets to port and starboard
• Adjustable wall lamps at head of bed
• Wood planking on hull sides
• Basket weave headboard
• Opening ports (4)
• Overhead opening hatch

Portside Guest Cabin:

• Bunkbeds with matching bedspreads
• Storage under bottom bunk
• Large wardrobe with shelves

Seperate Head:

• With accessories (mirror, towel rack, halogen celing light)
• Toilet (electic with holding tank)
• Sink with hot and cold water, single mixer tap
• Shower
• Opening port

GALLEY

The Galley is well laid out with all the needed essentials to make this very usable whether preparing meals for the crew while under way on a long trip or sitting in a quiet anchorage. With the 2 refrigerators, separate freezer and lots of dry goods storage you will never run out of space for your food and beverage supplies. When it comes time to clean up the large double S.S. sinks and SileStone counter tops all help to make your life easier.

• (2) Burner ceramic top electric stove (Kenyon)
• (2) Large stainless steel sinks w/ single lever swivel faucet
• (4) Large drawers
• Large under counter storage
• Smaller well divided storage above counter with doors
• Refrigerator under galley counter
• 2nd refrigerator (located under helm seat)
• SileStone counter tops

NAVIGATION and ELECTRONICS

All electronics are Raymarine and fully integrated and located both in the wheelhouse and on the flybridge. The engine controls are state of the art single lever Volvo controls with full function from both locations including full lock out feature.

• Raymarine E120 Hybridtouch GPS-Plotter at flybridge and helm
• Raymarine Depth-Speed
• Raymarine 7001 Autopilot
• Raymarine Radar
• Icom VHF
• Searchlight
• VHF
• Garmin GPS Plotter
• Twin Speaker sound system with AM/FM-CD-Ipod
• Sirius Radio
• Flat Screen wall mounted TV in master cabin with DVD player

ELECTRICAL

 120 Volt

• (2) 30 amp services
• (2) 50' shore cords
• (2) Covered outside 30 amp breakers at the source of incoming shore power
• Electric panel 120v (paneltronics with A/B cross over)
• 50 Amp battery charger (Mastervolt)
• Mastervolt 6000 Generator ( hours)
• 120v. recepticals (9 CFCI protected)
• Stove Top (ceramic (2) burner electric stove by Kenyon)
• Microwave (Sharp, built-in)
• Air Conditioning (2) 16,000 BTU units with reverse cycle heat

12 Volt

• Master battery disconnet switches
• Engine battery crossover switch
• Engines have 50 amp alternators
• Electric windlass (Lafrons)
• 12v. outlet
• Built in remote operated spotlight
• NEW 2018 engine batteries (2) 8D's
• NEW 2018 house batteries 8D's
• NEW 2019 bow thruster battery 4D
• NEW 2020 generator battery
• Interior lights have all been switched to LED
• Running lights have been switched to LED
• Anchor light has been switched to LED

PLUMBING

• Water heater
• Bilge pumps (2 electric)
• Toilet (1 electric Tecma)
• Holding tank (bladder)
• Fresh water pressure pump
• Shower in head compartment
• Fresh water tank
• Deck wash pump
• Cockpit shower (hot & cold)

DECK EQUIPMENT

The aft deck is very deep, dry and is covered with an extended hardtop with built in lighting and pull out canvas extention. This area has (2) built in seats that provide quick easy storage for dock lines. There are (2) director’s chairs and (2) director’s stools to be used with the folding table. There is a beautifully made solid teak door that leads to the steps and onto the large comfortable swim platform. On the starboard side there is a folding (5) step swim ladder. Hot and cold shower can be accessed from the swim platform as well as from the cockpit.

Moving forward from the cockpit you will find two large lockers beneath the walk way with the fuel fills located beneath the locker lids. This entire walk way has high bulwarks and solid stainless steel handrails that encompass the entire yacht providing you with a very safe and comfortable feeling when moving around the boat. And moving around the deck is something you will want to do as the foredeck area (approximately 88 sq. ft. is covered by thick 3" padding making it an ideal area for sun bathing and entertaining while watching the sun set (this pad has it's own sunbrella cover).

Forward is an anchor platform with horizontal Lafrons windlass complete with a stainless steel Bruce style anchor and ALL Stainless Steel chain rode. Controls for the windlass can be controlled with foot controls up front or wheel house. Moving aft on the port side you have access to the wheelhouse roof top.

• Padded deck covers
• Pilothouse window covers
• (2) Built in seats w/ storage for dock lines
• (2) Directors chairs
• (2) Directors Stools
• Folding wood dining table
• Hot & cold shower access from swim platform
• Solid teak doors
• Anchor platform
• Self draining anchor locker
• Cleats and fairleads
• Fiberglass bow sprit with SS pulley
• Stainless steel mooring bits and cable guides
• Fresh water shower on swim platform
• Teak cap rail
• Cross tree in teak
• Generous access to engine room
• Regulation navigation lights
• Bow railings in stainless steel, stern railings in teak
• Fuel fill (2) located beneath walkway locker lids

ENGINE ROOM

• Special soundproofing in engine room
• Engine water intakes w/ seacock (2) for engines in marine brass w/ seawater strainer
• Generator water intake w/ seacock (1) for generator with seawater strainer
• Emergency fuel shut off switch on control panel
• Ventilation via external air pipes
• Overhead lighting
• Automatic bilge pump
• Diesel tank (2) x 118 gallons total 236 gallons
• Fuel level gauge

FUEL CONSUMPTION CHART

R.P.M._____GPH_______Knots_____Hours_______Miles

1,600______3.7_________8.7________56_________488

1,800______4.7_________9.4________44_________410

2,000______6.3________10.2________33_________332

2,200______8.5________11.3________25_________277

2,400______10.6_______13.5________20_________264

2,600______13.2_______15.2________16_________238

2,800______16.4_______16.8________13_________212

3,000______20.6_______17.7________10_________178

3,200______25.4_______18.9________8__________155

3,400______31.2_______20.2________7__________134
